TrojanUVFlexAOP™

UV advanced oxidation for potable reuse & drinking water remediation. Communities around the world are facing a growing water stress – an insufficient supply, in terms of water quality or water quantity – and often both. Many are turning to potable reuse and drinking water remediation to meet these demands. The TrojanUVFlex®AOP can be part of the solution

Enquire

If you are interested in purchasing this product, please get in touch.

Meeting the demand for clean water has never been more challenging. The UV Advanced Oxidation Process (also known as UV AOP) can help municipalities relying on lower quality water sources to continue producing high-quality drinking water for their communities. UV AOP does this by destroying a range of environmental contaminants while simultaneously providing final disinfection to inactivate bacteria, protozoa and viruses.

TrojanUV advanced oxidation systems are installed in both reuse and remediation applications  treating a variety of contaminants such as 1,4-dioxane, taste and odour causing compounds, NDMA, and pesticides. With decades of experience in the design of UV AOP systems and dozens of full-scale installations around the world, Trojan is a global leader in the application of UV AOP technology.

Advanced Oxidation

The TrojanUVFlex™AOP is ideally suited to deliver on the contaminant treatment challenges associated with potable wastewater reuse and the removal of chemical contaminants in treated drinking water. This includes the capability to destroy common contaminants, such as 1,4-dioxane and NDMA, to negligible levels.

In addition, the TrojanUVFlex™AOP is third-party validated to provide disinfection credits and can deliver up to 6-log (99.9999%) inactivation of pathogens including Cryptosporidium, Giardia, and viruses among others

The TrojanUVFlex offers a significantly reduced footprint and installation cost

  • Lamp array optimised for highest UV dose delivery in the smallest footprint
  • Lamps are perpendicular to flow reducing overall train length
  • Flexible UV chamber can be installed horizontally or vertically
  • Modular lamp sections enable expandability, redundancy and lowest power consumption
  • Low headloss design reduces or eliminates pumping
  • Overall footprint reduced by 40-50% vs. other high-efficiency UV-oxidation systems

FILTEC Municipal UV Catalogue

TrojanUVFlexAOP Brochure

TrojanUV Solo Lamp, Replacement UV lamp for the UVFlex100, SKU – 908081-007

Replacement quartz sleeve kit for the TrojanUVFlex® and TrojanUVFlex®AOP 200 Series, SKU – 822518

Replacement Lamp Driver for the TrojanUVSigna, TrojanUVFlex, TrojanUVFlexAOP and TrojanUVTorrent, SKU – 916841

Size

TrojanUVFlexAOP 100 series, TrojanUVFlexAOP 200 series
